STA1/STA2 Series Explosion Proof Light

The STA1/STA2 Series LED Explosion Proof Light is the ideal choice for marine and hazardous applications. They can be used in locations where moisture, dirt, dust, corrosion and vibration may be present, orareas where wind, water, snow or high ambient can be expected.

APPLICATIONS
1、Suitable for illumination of hazardous locations designated as Zone 2 where ignitable gases are present.
2、Designed to illuminate roads in chemical and petrochemical plants, refineries and other process industries where ignitable gases are present.

TECHNICAL DATA
Body material：Aluminum alloy with epoxy powder coating
Diffuser：Tempered glass
Rated voltage：220 V - 240 V AC 50 Hz / 60 Hz
Wattage：100W 150W 200W
Luminous efficiency：140 lm / W
Degree of protection：IP65
Cable entry：G3/4
Corrosion-proof class：WF2

FEATURES
1、Designed to use in Zone 2 and Zone 21
2、LED light source providing high luminous efficacy and long life
3、Optional diffuser available
4、Multiple mounting options
5、Superior vibration resistance
6、Degree of protection up to IP65

DIMENSION DRAWINGS
